特点:
- 紧凑型小4U机箱
- 支持Intel® 10/11th Generation Core/Pentium/Celeron Desktop CPU
- 安装标准ATX主板，支持标准4U电源
- 最多支持7槽位全高卡扩展，满足多行业应用需求
- 人性化设计，机箱前置系统风扇免工具维护
- 精心设计的免工具PCIe扩展卡固定架、具有更高的抗震性
- 最多可选2个3.5英寸抗震抗冲击硬盘位
- 前⾯板USB、开关机设计，电源及存储状态显⽰，更易于系统维护
| Model | IPC350-H470 | |
| Processor System | CPU | Support Intel® 10/11th Generation Core / Pentium/ Celeron Desktop CPU |
| TDP | 125W | |
| Socket | LGA1200 | |
| Chipset | H470 | |
| BIOS | AMI 256 Mbit SPI | |
| Memory | Socket | 2 * Non-ECC U-DIMM Slot, Dual Channel DDR4 up to 2933MHz |
| Capacity | 64GB, Single Max. 32GB | |
| Graphics | Controller | Intel® HD Graphics |
| Ethernet | Controller | 1 * Intel i225-V LAN Chip (10/100/1000/2500 Mbps, RJ45) 1 * Intel i219-LM GBE LAN Chip (10/100/1000 Mbps, RJ45) |
| Storage | SATA | 3 * SATA3.0 7P Connector |
| M.2 | 1 * M.2 Key-M Slot (PCIe 3.0 x4 + SATA 3.0, NVMe/ SATA SSD Auto Detect, 2242/2260/2280) | |
| Expansion Slots | PCIe | 1 * PCIe x16 slot (Gen 3, x16 signal) 1 * PCIe x4 slot (Gen 3, x1 signal) 1 * PCIe x4 slot (Gen 3, x1 signal) |
| PCI | 4 * PCI slot | |
| Mini PCIe | 1 * Mini PCIe (PCIe 3.0×1+USB 2.0, with 1 * SIM Card slot) | |
| Front I/O | Ethernet | 2 * RJ45 |
| USB | 4 * USB 5Gbps (Type-A, 5Gbps, 2 ports for a total of 3A) 2 * USB2.0 (Type-A, 2 ports for a total of 2A) | |
| PS/2 | 1 * PS/2 (Keyboard & Mouse) | |
| Display | 1 * DVI-D: max resolution up to 1920*1200 @ 60Hz 1 * HDMI1.4: max resolution up to 3840*2160 @ 30Hz | |
| Audio | 3 * 3.5mm Jack (Line-out + Line-in + MIC) | |
| Serial | 2 * RS232/422/485 (COM1/2, DB9/M, Full Lanes, BIOS Switch) | |
| Rear I/O | USB | 2 * USB2.0 (Type-A) |
| Button | 1 * Power Button | |
| LED | 1 * Power status LED 1 * Hard drive status LED | |
| Internal I/O | USB | 2 * USB 5Gbps (F_USB 5Gbps, wafer) 1 * USB2.0 (USB2_1, Vertical type connector) 2 * USB2.0 (F_USB2_1, header) |
| COM | 4 * RS232 (COM3/4/5/6, Header, Full Lanes) | |
| Display | 1 * VGA: max resolution up to 1920*1200 @ 60Hz (wafer) 1 * eDP: max resolution up to 1920*1200 @ 60Hz (Header) | |
| Audio | 1 * Front Audio (Line-Out + MIC, Header) 1 * Speaker (3W (per channel) into a 4Ω Loads, wafer) | |
| GPIO | 1 * 16 bits DIO (8DI and 8DO, wafer) | |
| SATA | 3 * SATA 7P Connector | |
| LPT | 1 * LPT (Header) | |
| FAN | 2 * SYS FAN (Header) 1 * CPU FAN (Header) | |
| Power Supply | Type | ATX |
| Power Input Voltage | AC power supply, voltage and frequency shall be based on the ATX power supply provided | |
| RTC Battery | CR2032 Coin Cell | |
| OS Support | Windows | Windows 10/11 |
| Linux | Linux | |
| Watchdog | Output | System Reset |
| Interval | Programmable 1 ~ 255 sec | |
| Mechanical | Enclosure Material | SGCC |
| Dimensions | 330mm(L) * 351mm(W) * 180mm(H) | |
| Mounting | Wall mounted, Desktop | |
| Environment | Heat Dissipation System | PWM fan cooling |
| Operating Temperature | 0 ~ 50℃ | |
| Storage Temperature | -20 ~ 70℃ | |
| Relative Humidity | 10 to 95% RH (non-condensing) | |
